MPBBB

Features Hardened,precision ground parts for durability Compact size Industry common cavity Fast response to pressure surges Adjustment prevents spring from going solid

邮箱：sales@meric.cn

在线留言

产品详情

MPBBB MPBBB

Specifications

Operating Pressure 350BAR

Flow 75L/min

Internal Leakage 85cc/min.max.to 85% of norminal setting

Temperature -30°C to +120°C(-22°F to+250°F)

Cavity 10-2 see page K-11

Fluids Mineral-based fluids with viscosities of 7.4 to 420 cSt.

Features

Hardened,precision ground parts for durability

Compact size

Industry common cavity

Fast response to pressure surges

Adjustment prevents spring from going solid

Operation

The valve is a direct-acting,dual cross-over relidf valve in a single cartridge

format,When pressure at either port exceeds the nominal setting value, flow

will be transmitted to the opposite port. Back pressure at either port will affect

the nominal setting of the opposite port on a 1 :1 basis.

None
